sudo nano /etc/systemd/system/dbus-org.bluez.service
ExecStart=/usr/lib/bluetooth/bluetoothd -C
ExecStartPost=/usr/bin/sdptool add SP
from bluetooth import *
import time
while True:
server_sock=BluetoothSocket( RFCOMM )
server_sock.bind(("",PORT_ANY))
server_sock.listen(1)
print " listening "
try:
client_sock,address = server_sock.accept()
print "Accepted connection from ",address
while 1:
try:
data = client_sock.recv(1024)
# if len(data) == 0: break
print "received %s" % data
x, y, z = [int(val) for val in data.split(',')]
print "received 1st %s" % x
print "received 2nd %s" % y
print "received 3rd %s" % z
except IOError:
print "connection disconnected"
break
except KeyboardInterrupt:
client_sock.close()
sys.exit()
except KeyboardInterrupt:
server_sock.close()
sys.exit()
from bluetooth import *
import RPi.GPIO as GPIO
import time
GPIO.setwarnings(False)
GPIO.setmode(GPIO.BOARD)
#*****************GPIO setup ***************************
GPIO.setup(3,GPIO.OUT) #Left wheel motor control
GPIO.setup(5,GPIO.OUT) #Left wheel motor control
GPIO.setup(7,GPIO.OUT) #right wheel motor control
GPIO.setup(11,GPIO.OUT) #right wheel motor control
#Motor stop/brake
GPIO.output(3,0)
GPIO.output(5,0)
GPIO.output(7,0)
GPIO.output(11,0)
while True:
server_sock=BluetoothSocket( RFCOMM )
server_sock.bind(("",PORT_ANY))
server_sock.listen(1)
print " listening "
try:
client_sock,address = server_sock.accept()
print "Accepted connection from ",address
while True:
try:
data = client_sock.recv(1024)
#print "received %s" % data
c,data1 = [str(val) for val in data.split(':')]
x, y, z = [int(val) for val in data1.split(',')]
print "c,x,y,z",c,x,y,z
if c==0:
if x>0 and y>0: # Move front - Depends on your Motor assigned
GPIO.output(3,0)
GPIO.output(5,0)
GPIO.output(7,1)
GPIO.output(11,1)
elif x<0 and y<0: # Move back- Depends on your Motor assigned
GPIO.output(3,1)
GPIO.output(5,1)
GPIO.output(7,0)
GPIO.output(11,0)
elif x>0 and y<0: # Move right - Depends on your Motor assigned
GPIO.output(3,0)
GPIO.output(5,1)
GPIO.output(7,1)
GPIO.output(11,0)
elif x<0 and y>0: # Move left - Depends on your Motor assigned
GPIO.output(3,1)
GPIO.output(5,0)
GPIO.output(7,0)
GPIO.output(11,1)
else: # Stop
GPIO.output(3,0)
GPIO.output(5,0)
GPIO.output(7,0)
GPIO.output(11,0)
time.sleep(1)
elif c==1:
except IOError:
print "connection disconnected"
break
except KeyboardInterrupt:
client_sock.close()
sys.exit()
except KeyboardInterrupt:
server_sock.close()
sys.exit()
